Kyocera Ecosys M8124cidn A3A4 Colour Multifunction Laser Printer

Engine speed: Up to 30 pages A4 per minute in colour and b/w

Resolution: 1200 x 1200 dpi (print, at reduced speed), 600 x 600 dpi (scan/copy)

Warm-up time: Approx. 26 seconds or less

Time to first print: Approx. 6.5/7.5 seconds or less in b/w / colour

Time to first copy: Approx. 8.5/10 seconds or less in b/w / colour

Duplex unit: Duplex as standard supports 60 – 163 g/m²; A4, A5, B5, Letter, Legal

Max. input capacity with options: 1,850 sheets

This A4 colour device is designed specifically for medium and large-sized work groups, offering both reliability and fast 30ppm output.

Kyocera solutions always work with the environment in mind, but the ECOSYS range do this more than any other product on the market.

Multi-Functional Products for day-to-day tasks

Kyocera provides the industry’s most comprehensive line of award-winning low to high volume devices.

A3 and A4 printers for all needs

High quality, high reliability and high efficiency are essential.

ECOSYS: The sustainable solution

Unique to Kyocera, ECOSYS provides long-last and environmentally friendly printers at an economical cost.

Technical Specifications

General

General type: Colour multifunctional for A4 format

Technology: KYOCERA ECOSYS, Colour Laser

Engine speed: Up to 30 pages A4 per minute in colour and b/w

Resolution: 1200 x 1200 dpi (print, at reduced speed), 600 x 600 dpi (scan/copy)

Warm-up time: Approx. 26 seconds or less

Time to first print: Approx. 6.5/7.5 seconds or less in b/w / colour

Time to first copy: Approx. 8.5/10 seconds or less in b/w / colour

Dimensions (W x D x H): 475 x 558 x 616 mm

Weight: Approx. 35,4 kg including toner container

Power consumption: Printing: 496 W Copying: 521 W Low power mode: — W Ready mode: 70 W Sleep-mode: 0.6 W

Power source: AC 220 ~ 240 В, 50/60 Гц

Noise (ISO 7779): Noise (Sound pressure level: ISO 7779 / ISO 9296) Copy / Print in colour: 49.5 dB(A) LpA, Quiet mode in colour: dB(A) LpA, Sleep-mode: Immeasurable low

Safety standards: TÜV/GS, CE – This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard.

General memory: Standard 1024 MB, max. 2.048 MB

Print

Processor: Cortex-A9 Dual core 1,2 GHz

Controller language: PRESCRIBE IIc

Emulations: PCL6 (5c/XL), KPDL3 (PostScript 3 compatible), PDF Direct Print, XPS Direct Print

Fonts: 93 outline fonts (PCL), 93 fonts (KPDL 3), 8 fonts (Windows Vista), 1 Bitmap font, 45 types of onedimensional barcodes, 1 type of two-dimensional barcode (PDF417)

Integrated Accounting: 100 department codes

Features: Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, quick copy, proof and hold, private print, job storage and job management functionality

Protocol: Mobile printing support: KYOCERA Mobile Print app for iOS and Android, AirPrint, Mopria

Applicable OS: All current Windows operating systems, MAC OS X Version 10.8 or higher, Unix, Linux as well as other operating systems on request

Copy

Max. original size: A4/legal

Digital copy features: Scan-once-copy-many, electronic sort (collate), ID card copy, 2in1, 4in1, auto cassette change, Skip blank page

Exposure modes: Auto, manual: 9 steps

Preset magnification ratios: 7 Reductions / 5 Enlargements

Zoom range: 25 – 400 % in 1% steps

Continuous copy: 1 – 999

Image adjustments: Text + Photo, Photo, Text, Map, Printed document

Scan

Compression format: MMR/JPEG

File type: TIFF, PDF, PDF/A, JPEG, XPS, Open XPS, Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u, MS Office file and Searchable PDF (optional Scan Extension Kit(A) is required)

Scan features: Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Blank page skip

Original recognition: Text, photo, text + photo, light text, optimised for OCR

Max. scan size: A4 / legal

Scan functionalities: Scan-to-Email, Scan-to-FTP, Scan-to-SMB, Scan to USB Host, Local/Network TWAIN, WIA , WSD scan

Scan resolution: 600, 400, 300, 200 dpi, 256 greyscales per colour

Scan speed: 60 ipm (300 dpi, A4, b/w), 40 ipm (300 dpi,A4 colour), 26 ipm (300 dpi, A4, b/w) (Duplex), 17 ipm (300 dpi, A4 colour) (Duplex)

Paper Handling

Input capacity: 100-sheet multi-purpose tray, 60–220 g/m2, A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (70 x 148 to 216 x 356 mm), 250-sheet Standard universal paper cassette, 60–163 g/m2, A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm)

Max. input capacity with options: 1,850 sheets

Duplex unit: Duplex as standard supports 60 – 163 g/m²; A4, A5, B5, Letter, Legal

Max. output capacity: Max. 250 sheets face-down with paper full sensor

Document processor: Reversing document processor: 75-sheet, 50–120 g/m², A4, A5, A6, B5, Letter, Legal, Custom (105 x 148 to 216 x 356 mm)

General paper handling: All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions.

Standard interface: Standard interface: USB 2.0 (Hi-Speed), 2 x USB Host Interface, Gigabit Ethernet (10BaseT/100BaseTX/1000BaseT, IPv6, IPv4, IPSec, 802.3az support), optional Wi-Fi (IEEE 802.11b/g/n), 1 eKUIO slot for optional internal print server, Slot for optional SD Card
